Probe List
Probe Matrix
Probe Matrix “For European Union countries”
Probe Matrix “For Non-EU countries”
Standard probes
Vascular probe, Freq.: 4, 5, 8 & 10MHz
2MHz probe
Pencil probes
Standard, Freq.: 8MHz
Flat monitoring probes
Standard, Freq.: 8MHz
2MHz flat waterproof probe
Reusable Pulsed Wave probes with Amplifier (Sterilization methods: Sterrad(STERRAD®applicable list))
Pencil probe, Freq.:8,10 & 20MHz
Bayonet probe, Freq.: 10 & 20MHz, Diam.:2mm
Flexible probe, Freq.: 10 & 20MHz,
Diam.: 2.0mm (10MHz), 1.2mm (20MHz)
Bayonet probe, extra-thin, Freq.: 20MHz, Diam.:0.8mm
Note: Only available for DVM-4500.
Flexible probe, Freq.: 10MHz & 20MHz,
Diam.: 2.0mm (10MHz), 1.2mm (20MHz)
Note: Only available for DVM-4500.
Tucking probe, Freq.: 10MHz, Diam.:3, 4 and 5mm
Note: Only available for DVM-4500.
Flat monitoring probe, Freq.: 8MHz
5 times Autoclavable probe, Freq.: 8MHz
Note: 5 time autoclavable for sterilization.
･30 minutes at 121 degrees(℃).
･10 minutes at 134 degrees(℃).
* Do not expose the probe to
temperatures exceed 134 degrees(℃).
Long probe, Freq.: 8MHz,
Dimensions: 4.8mm diam. x 350mm long
Curved probe, Freq.: 10 & 20MHz,
Diam.: 1.2mm & 2mm
Single-use probes (*Contact us for more details.)
Bayonet probe, Freq.: 10 & 20MHz
Amplifier
Amplifier for PW probes, Freq.:8, 10 & 20MHz
Note: Not sterilizable. Use same freq. as probe.
Not required for 10 & 20MHz with DVM-4500.
PPG probes
PPG probe
Foot temperature probes
Foot temperature probe
